HBM WE2107 - Transmit Device Data (Back up Device Parameters)

WE2107 - Communication commands
76
I1820-1.3 enHBM
Transmit Device Data
(Back up device parameters)
Property Content Note
Command string TDD
No. of parameters 1
Parameter range P1 = 1 to store the parameter
P1 = 0 to restore the factory default
Factory default ‐
Reaction time < 0.2 s
Password protection No
Relevant to legal for
trade
No
Parameter backup No data to back up
Input Master TDD(P1); No response
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
This command is used to save all the parameters. The WE has two EEPROM. In the first
EEPROM, customer‐specific parameters are stored power fail safe. The second EEPROM
contains the legal for trade parameters.
Content of the first EEPROM:
ADR
, BDR, COF, SFU, ASF,, FMD, TAV, TAS,
ED1
, ED2, EDC, ESC, PES, PID, PLB, PLE, PRT, PST, TAD, TDL, EPT, RFT,
MDT
, FRS, LIV, BFL, BFS, FIN, MAL, DPW
Content of the second EEPROM (legal for trade parameters)
SZA
, SFA, ACA, ACU, CWT, LDW, LWT, NOV, RSN, MRA, MRB, MDT, ENU, DPT,LIN, LIM,
ZSE
, ZTR, LFT, TCR.
If LFT>0 only the parameters of the first EEPROM will be stored.
If LFT=0 the parameters of both EEPROM will be stored.
A TDD? query is not permitted.
TDD
