HBM WE2107 - External Display Check Sum

95
WE2107 - Communication commands
I1820-1.3 en HBM
External display check sum
(Protocol external display definition of the check sum)
Property Content Note
Command string EDC
No. of parameters 1
Parameter range 0,1
Factory default 0
Reaction time < 15 ms
Password protection No
Relevant to legal for
trade
No
Parameter backup With command TDD1
Input Master EDC(P1); No response
Query Master EDC?;
Response WE x crlf 1 characters
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
This command defines the checksum in the output string.
EDC = 0: no check sum is defined (the telegram is 1 byte shorter)
EDC = 1 an check sum will be calculated
The check sum is the XOR function ( first byte is the start character (EDS) and
The last byte is the end character 2 (ED2).
EDC
