HBM WE2107 - Multi Range Mode 1 (2‐Range Weighing Display)

WE2107 - Communication commands
48
I1820-1.3 enHBM
Multi Range Mode 1
(2‐range weighing display)
Property Content Note
Command string MRA
No. of parameters 1
Parameter range P1=0...NOV (99999) 0=disabled
Factory default 0
Reaction time <15 ms
Password protection Yes
Relevant to legal for
trade
Yes
Parameter backup With command TDD1
Input Master MRA(P1); No response
Query Master MRA?;
Response WE P1crlf P1 = 6 characters
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
The command is used to set up the scale as a one or two‐range scale. At MRA0; 2‐range
mode is deactivated. With MRA>0 ... NOV, it is possible to specify the changeover point
between ranges 1 and 2. If 2‐range mode is enabled, the set RSN increment is valid for
range 1. The increment for range 2 is then automatically the next increment:
Examples:
RSN=2: Range 1 with increment 2, range 2 with increment 5
RSN=5: Range 1 with increment 5, range 2 with increment 10
The display switches back to the increment of range 1 if the scale is unloaded.
MRA
