WE2107 - Communication commands
36
I1820-1.3 enHBM
3.3 Scale characteristic curve and output scaling
D Scale characteristic curve adjustment: LDW, LWT
D Partial load parameter for LDW, LWT: CWT
D Measured value scaling: NOV
D Unit of measurement: ENU
D Increment: RSN
D Decimal point: DPT
D Motion detection: MDT
D 2‐range display: MRA
D 3‐range display: MRB
You can adapt the WE characteristic curve to your particular requirements with the command
pair LDW/LWT.
With the CWT command, the user curve can also be set with a partial load.
NOTE
The characteristic curve commands LDW and LWT should be entered or executed in the
following order: LDW followed by LWT. The input data is only offset if these two parameters
have been entered or measured in pairs.
After the scale adjustment the range LDW → LWT is assigned to the following number
ranges:
Output at max. capacity (COF)
NOV w 100
2‐byte binary NOV value
4‐byte binary NOV value
ASCII NOV value
