HBM WE2107 - Load Cell Dead Weight (Scale Curve Zero Point)

WE2107 - Communication commands
38
I1820-1.3 enHBM
Load Cell Dead Weight
(Scale curve zero point)
Property Content Note
Command string LDW
No. of parameters 1
Parameter range P1=0...+
399999
Factory default 0
Reaction time <15 ms on input or query
Password protection Yes
Relevant to legal for
trade
Yes
Parameter backup after input of LWT with TDD1;
Input Master LDW(P1); on response
Query Master LDW?;
Response WE P1crlf
(P1= 6‐digit plus sign)
P1 = 7 characters
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
When measuring, the current input signal (e.g. scale not loaded, but with dead load) assigns
the output value 0 digits to the internal measured value.
Parameter description:
For a query, the value is output ±6‐digit (e.g. ‐000246 CRLF).
The user curve is disabled at LDW=0 and LWT=200000.
The LDW
value is not converted via NOV.
To perform the scale adjustment see command LWT
.
LDW
