HBM WE2107 - Sensor Fullscale Adjust (Factory Default Curve Full Scale)

WE2107 - Communication commands
32
I1820-1.3 enHBM
Sensor Fullscale Adjust
(factory default curve full scale)
Property Content Note
Command string SFA
No. of parameters 1
Parameter range P1=0...+
399999
Factory default Adjustment to 2mV/V (200000d)
Reaction time <15 ms
Password protection Yes
Relevant to legal for
trade
Yes
Parameter backup With command TDD1;
Input Master SFA(P1); No response
Query Master SFA?;
Response WE P1crlf
(P1= 6‐digit plus sign)
P1 = 7 characters
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
For an input signal of 2 mV/V, the output value 200000 digits is assigned to the internal
measured value for ASCII output.
Parameter description:
For a query, the value is output ±6‐digit (e.g. ‐350246 LF).
The curve is disabled at SZA=0 and SFA=200000.
SFA
