HBM WE2107 - Error Status

WE2107 - Communication commands
78
I1820-1.3 enHBM
Error status
(Error status)
Property Content Note
Command string ERR?
No. of parameters ‐
Parameter range ‐
Factory default ‐
Reaction time < 15 ms
Password protection No
Relevant to legal for
trade
no
Parameter backup ‐
Query Master ERR?;
Response WE P1 crlf P1 = 3 characters
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
The Error code has a range of 0…255 (decimal, ERR=0 == no Error). After reading the error
status the error memory is set to zero.
An error can be detected by the status of the measured value (Bit7=1).
The error status is coded bit by bit. If several errors occurs at the same time than the
individual error bits (3…0) are set to error with the highest priority.
Error
Error bit
Hardware Bit 7 = 1 (priority high)
Load cell / sensor Bit 6 = 1
Parameter Bit 5 = 1
Communication Bit 4 = 1 (priority low)
Individual error bits Bit 3…0
ERR
