HBM WE2107 - Page 79

79
WE2107 - Communication commands
I1820-1.3 en HBM
Error bits 3…0 Error hardware (Bit 7 = 1)
0 ‐ ( no or several errors)
1 Internal EEPROM (checksum)
2 External EEPROM (checksum)
3 ADC overflow (AOV)
4 ADC underflow (AOV)
5 External power supply voltage to low
6 Short cut digital OUT1…4
7 Internal voltage too low < 7.0 V
Error bits 3…0 Error load cell (Bit 6 = 1)
0 ‐ ( no or several errors)
1 Sensor overflow (SOV)
2 Sensor underflow (SOV)
3 Sensor excitation voltage too low (< 3 V)
4 Floating bridge input signal
5 … 7 Tbd
