WE2107 - Communication commands
I1820-1.3 en HBM
Load Weight
(Scale characteristic curve full scale)
Property Content Note
Command string LWT
No. of parameters 1
Parameter range P1=0...+
399999
Factory default 200000
Reaction time <15 ms
Password protection Yes
Relevant to legal for
trade
Yes
Parameter backup With command TDD1;
Input Master LWT(P1); No response
Query Master LWT?;
Response WE P1crlf
(P1= 6‐digit plus sign)
P1 = 7 characters
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
When measuring, the current input signal (e.g. scale loaded= max. capacity) assigns the
output value 200000 digits to the internal measured value.
Parameter description:
For a query, the value is output ±6‐digit (e.g. ‐950246 CRLF).
The user curve is disabled at LDW
=0 and LWT=200000.
The LWT value is not converted via NOV
.
LWT
