HBM WE2107 - Configurate Output Format (Output Format for Data Outputs)

WE2107 - Communication commands
24
I1820-1.3 enHBM
Configurate Output Format
(Output format for data outputs)
Property Content Note
Command string COF
No. of parameters 1
Parameter range P1=0 ... 4
Factory default 2 binary with status
Reaction time <15 ms
Password protection No
Relevant to legal for
trade
No
Parameter backup With command TDD1;
Input Master COF(P1); No response
Query Master COF?;
Response WE P1crlf P1=1 character
Note: ( ) required parameters, < > optional parameters for parameter input
Function
The command is used to set up the output formats for the command MSV?.
The possible formats and the decimal number to enter for them are listed in the tables below.
The following format groups are supported:
D COF 0 ... 3 binary data output
D COF 4 ASCII data output
Data output relates to the nominal (rated) value set for the WE (see the NOV
command).
Output at max. capacity
NOV w 100
2‐byte binary NOV value
4‐byte binary NOV value
ASCII NOV value
With 2‐byte binary output, the NOV value must be v 30000, otherwise the measured value
will be output with overflow or underflow (7FFF
H
or 8000
H
). With NOV30000, the overload
reserve is only about 2700 digits.
COF
