WE2107 - Communication commands
92
I1820-1.3 enHBM
External display start character
(External display, definition of the start character)
Property Content Note
Command string EDS
No. of parameters 1
Parameter range 0 … 99
Factory default 0
Reaction time < 15 ms
Password protection No
Relevant to legal for trade No
Parameter backup With command TDD1
Input Master EDS(P1); No response
Query Master EDS?;
Response WE xx crlf 2 characters
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
This command defines the start character in the output string.
EDS=0: no start character is defined (the telegram is 1 byte shorter)
EDS=1…99 an start character is defined ( reference ASCII‐chart PC437)
Examples:
EDS=2: start character is STX (=02hex)
EDS=27: start character is an ESC (=1B hex)
EDS
