HBM WE2107 - External Display Protocol

WE2107 - Communication commands
88
I1820-1.3 enHBM
External display protocol
(Protocol external display via second serial link)
Property Content Note
Command string EDP
No. of parameters 1
Parameter range 0 … 7
Factory default 0
Reaction time < 15 ms
Password protection No
Relevant to legal for
trade
No
Parameter backup With command TDD1
Input Master EDP(P1); No response
Query Master EDP?;
Response WE X crlf 1 character
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
Definition of the output string:
P1 = 0: no external display (if printer is connected)
P1 = 1; output of the Gross‐ or Net value
P1 = 2; output of the Gross‐ or Net value and the tare value
P1 = 3; output of the filling result
P1 = 4; output of the Gross‐ or Net value with decimal point
(6 char.)
P1 = 5; output of the Gross‐ or Net value without decimal point
(5 char.)
From software version P73:
P1 = 6; Gross or net value is output without decimal separators. (6 characters)
with status
P1 = 7; Gross or net value is output without decimal separators. (6 characters)
The length of the output string depends on the start character (EDS), the both end
characters (ED1, ED2) and the check sum character (EDC).
EDP
