WE2107 - Communication commands
64
I1820-1.3 enHBM
Measured Internal Signal Value
(Measurement query)
Property Content Note
Command string MIV?
No. of parameters ‐
Parameter range ‐
Factory default ‐
Reaction time < 15 ms
Password protection No
Relevant to legal for
trade
No
Parameter backup No data to back up
Query Master MIV?;
Response WE Xxxs crlf 4 byte binary
Note: ( ) required parameters, < > optional parameters for parameter input
Function:
This command should be only used for the scale adjustment (LDW, LWT)
The output format for a measured value is fixed (COF2). The maximum extent of the meas
ured values is:
For 4‐byte data output: long integer "399999
The measured value is output in not in relation to the particular measuring range (NOV).
Output format measured value at max. capacity
0 mV/V 2 mV/V
4‐byte binary 0 200000
Binary output:
The length specification includes the end label (CR, LF).
With 4‐byte output, the measured value is a 3-byte value. The fourth byte is the measure
ment status
COF
Length Sequence for data output
COF2 6 bytes MSB before LSB (LSB=status)
MSB=most significant digit, LSB=least significant digit
MIV
