WE2107 - Communication commands
96
I1820-1.3 enHBM
3.10 Commands for setup the print function
D Print protocol PRT
D Escape sequence ESC
D Number of empty lines before printing PLB
D Number of empty spaces in each row PES
D Print identification counter PID
D Printer strings PST
D Number of empty lines after printing PLE
D Start a hard copy SHC
To start a hard copy a function button (F1/F2) or a digital input has to be set
(BUS, BUL, FIN
).
Via the second serial link a printer can be connected.
Baud rate: 1200...9600
Parity bit: non / even
Type: RS‐232
Protocol: Hardware – protocol (DTR)
Software – protocol (DC1/DC3/DC4)
The protocol has to be defined in the parameter menu (UART2/FUNCT) or with the com
mand FUB
.
The parity bit and the communication protocol has to be defined in the menu of the WE. The
different hard copies are described in the part 1 of the manual. . The baud rate can only be
selected in the parameter menu (there is no command available).
