WE2107 - Communication commands
42
I1820-1.3 enHBM
Parameter description:
P1 is a 6-digit decimal number in the range 10000 to 120000 (=10 % ... 120 %). With
P1=100000 (=100 %) this part load calibration is switched off.
P1 is a 6‐digit decimal number in the range 10000 to 99999 (=10 % ... 120 %) for none legal
for trade applications.
P1 is a 6‐digit decimal number in the range 20000 to 99999 (=20 % ... 120 %) for legal for
trade applications.
P1 is the percentage of the max. capacity with which the next LDW / LWT adjustment is to
be carried out.
P1:= 100000 * adjustment weight / max. capacity
Example:
The scale curve LDW/LWT of a scale is adjusted with 15 kg=15000 d. But the only
adjustment weight available for the adjustment is a 10 kg weight. Proceed as follows:
1. For the adjustment, set the CWT value to 66667 ( corresponds to 66 %).
2. For the adjustment, set the NOV value to 15000.
3. Then carry out an LDW/LWT adjustment.
After the adjustment, the WE outputs 10000 digits as the measured value at 10 kg and
15000 digits at 15 kg.
4. Set the increment to RSN5 and the decimal point to DPT3. This gives the number of
divisions as 3000 d=e and a display of 15,000 at 15 kg max. capacity.
NOTE
After an adjustment, the LDW and LWT values can be read out. They correspond to
parameters, as if the adjustment had been carried out at max. capacity (and not at partial
load). Should you want to enter the values for LDW and LWT again later, you must first enter
CWT=0, then the LDW value that has been read out and finally the value read out for LWT.
When the factory default curve is entered with SZA/SFA, this resets the user curve to the
default values LDW=0, LWT=200000 and CWT=100000.
