7.5 Measurement Data Saving
109
89
7
Chapter 7 Data Saving and File Operations
Dialog box setting items
Selecting the Destination Folder and Measurement Items to Save
Display the
[Interface] page
(A dialog appears)
For manual saving:
[Folder]
For auto-saving:
[Folder]
(Can be set when the auto
save mode is ON.)
Enter characters with the F keys
Enter:
Cancel:
keys to select
characters
Input Enters the character at the cursor position.
(The same as .)
BS Deletes the character before the cursor position.
Del Deletes the character at the cursor position.
Pos←/Pos→ Moves the cursor position.
OK Accepts the entered file name. After accepting, closes the dialog.
• When auto-saving is enabled, manual saving is not available.
• Folder names can be up to eight characters.
To Next Page
