Hioki 3390 - Setting the Sampling Frequency and Points

4.6 Viewing Noise Measurement Values (FFT Function)
73
4
Chapter 4 Viewing Measurement Values
Set the FFT sampling rate and number of points according to the frequency of the noise to be analyzed.
These settings are on the [Calc] page of the Setting screen.
Sampling can be selected at the [Noise] setting on the [Wave + Noise] page of the Measurement screen.
See How to display: "Displaying Noise" (p. 72)
4.6.2 Setting the Sampling Frequency and Points
Changing Sampling on the Measurement Screen
Select the item
Display the
[Calc] page
Select with the F keys
See Screen display procedure:"Displaying
Noise" (p. 72)
Select the item
Enter
Selects from the pull-down
menu
Cancel
Displays the pull-down
menu
