7.5 Measurement Data Saving
112
The items to be saved to storage media can be selected.
The number of items that can be recorded depends on the interval timing setting.
*
: Setting Contents
7.5.3 Selecting Measurement Items to Save
Interval 50ms 100ms 200ms 500ms 1s Other
Maximum
recordable items
130 260 520 1300 2600 5000
Setting Procedure
Display the
[Interface] page
Select measurement contents
with the
F keys.
Select
[Items to save]
Set by F keys*
(Press to toggle off/on.)
Select the items to be
saved.
Press to select Noise
peak, Temp, ChA, ChB, Pm,
and Slip.
Press (or ) to return to the
previous page.
"O" indicates ON, blank indicates
OFF, and "-" indicates not selectable.
No. of items to record
Indicates the number of data
items enabled (set to “ON”)
Maximum recording quantity
determined by the interval setting
OFF Saving disabled
ON Saving enabled
All CH set Sets all channels ON or OFF
(not displayed when [Other] is selected).
See "Using [All CH Set]" (p. 16)
All OFF Sets all selected items OFF.
All ON Sets all selected items ON.
To Next Page
