[CH1 to CH4]
[Efficiency]
[Motor]
[XY Graph]
[Wave + Noise]
[Vector]
[Select]
Measurement Screen (Press the key to display)
Press the keys to change the screen page as follows.
This screen displays measurement values.
This page displays measured voltage, current, and
power on channels 1 to 4 as numerical values
and as vectors.
This page displays measured values for the
motor analysis options.
This page displays an X-Y graph of measurement
parameters selected for horizontal and vertical
axes.
This page displays the numerical values of efficiency
and loss determined by calculation formulas.
This page displays measured power, voltage and current
values, integration values, and provides access to
harmonic graphs and lists for each channel.
This page displays voltage, current, and noise
waveforms. The waveforms can be saved.
Select any parameter on this page for display.
Appears only when
the Model 9791 Mo-
tor Testing option or
the 9793 Motor Test-
ing & D/A Output op-
tion is installed.
To Next Page
