4.4 Viewing Harmonic Measurement Values
68
Select whether to use THD-F or THD-R method to calculated total harmonic distortion. The selected cal-
culation method is applicable to both harmonic voltage and current.
4.4.5 Selecting the THD Calculation Method
THD-F The percentage of total harmonics relative to the fundamental waveform
THD-R
The percentage of total harmonics relative to the sum of the total harmonics and the funda-
mental waveform
Display the
[Input] page
Select with the F keys
What is THD?
THD is an abbreviation for total harmonic distortion: the total amount of signal distortion cause
by all harmonics.
Select the item
