7.8 Saving Setting Configurations
115
89
7
Chapter 7 Data Saving and File Operations
Various instrument settings can be saved to storage media as "settings" files.
Dialog Box Setting Items
7.8 Saving Setting Configurations
Save Procedure (Example: saving to a CF card folder)
Display the
[CF card] page
(A dialog appears.)
Enter characters with the F keys.
Enter:
Cancel:
keys to select a character
or to open a folder
keys to select a folder
Input Enter the character at the cursor position.
(Same as )
BS Deletes the character to the left.
Del Deletes the character at the cursor position.
Pos ←/Pos→ Moves the cursor position.
OK Accepts the entered file name.
The dialog closes when accepted.
Save destination: CF card, USB flash drive
(Save destination setting is the same as for Manual saving, (p. 108))
File names: User-named (up to eight characters), file name extension is SET
Example: SETTING1.SET
• Language and communications settings are not saved.
• Setting configuration saving is not available during auto-saving.
• Folders within folders cannot be selected.
To Next Page
