10.3 Setting Specifications
161
10
10
Chapter 10 Specifications
6. Motor Measurement Settings (with motor evaluation option Model 9791 or 9793)
Synchronization source U1 to U4, I1 to I4, Ext (with channel B set for pulse input), DC (50ms/100ms)
Common to channels A and B
CHA Input Analog DC or frequency
CHArange ±1 V, ±5 V, ±10 V (for analog DC only)
Frequency range Select f
c
and f
d
for frequency range f
c
± f
d
[Hz] (frequency measurement only)
1 kHz to 98 kHz in 1 kHz units, where f
c
+ f
d
<100 kHz and f
c
– f
d
>1 kHz)
CHAScalling 0.01 to 9999.99(for analog DC only)
Rated torque 1 to 999 (frequency measurement only)
CHA Unit Analog DC:......V, N• m, mN• m, kN• m
Frequency: ......Hz, N
• m, mN• m, kN• m
CHB Input Analog DC or pulse
CHB range ±1 V, ± 5V, ±10 V (for analog DC only)
Motor poles 2 to 9 8(pulse input only)
Max. measurement frequency 100 Hz, 500 Hz, 1 kHz, 5 kHz (pulse input only)
Same as full-scale D/A output frequency setting
CHBScalling 0.01 to 9999.99 (for analog DC only)
Pulse count Integer multiple of half the number of motor poles, from 1 to 60000 (pulse input only)
CHB Analog DC:......V, Hz, r/ min
Pulse: ..............Hz, r/ min
CHZ OFF/ ON (pulse input only)
Measurement frequency source f1 to f4 (for slip calculations)
LPF OFF/ ON
7. Interface Settings
Synchronization control Master/slave
Synchronous event items HOLD, SAVE, COPY
Saving Data Select the items to record (Max. number of items is limited according to the interval setting.)
Auto-save OFF/ ON (CF card)
Data save destination Destination folder
Manual save destination USB memory, CF card (selected folder)
RS-232C connection destination Printer, Temperature tester
RS-232C communications speed 2400bps, 9600bps, 19200bps, 38400bps(2400 bps for thermometers)
IP address Four 3-digit octets (0 to 255)
Subnet mask Four 3-digit octets (0 to 255)
Default gateway Four 3-digit octets (0 to 255)
Temperature units setting Fahrenheit
8. System Settings
Display language Japanese, English
Beep sound OFF/ ON
Screen color schemes Color1, Color2, Color3, Color4, Mono
Start-up screen selection Wiring or Last-displayed screen (Measurement screens only)
LCD backlight ON, 1 min, 5 min, 10 min, 30 min, 60 min
Clock setting Year, month, day, hour and minute setting, and zero-second adjustment
System reset Reset
Serial number indication Displayed
Version indication Software version displayed
