8.2 Connecting a Thermometer (to acquire temperature data)
128
Make settings on the [Interface] page of the Setting screen.
Unit Setting for Temperature
Press , and keys simultaneously, so that the unit fortemperature can be selected
between deg.C and deg.F.
Turn on the thermometer and the instrument.
When thermometer measurement starts, temperature data is acquire by the instrument.
To display the temperature, select [OPT.] - [Temp] as the [Select] on the [
Select] page of the Measure-
ment screen.
See"Selecting Measured Items for Display" (p. 38)
Refer to "Chapter 7 Data Saving and File Operations" (p. 103).
Thermometer Settings on the Instrument
Setting Procedure
Display the
[Interface] page
Select
[RS connection]
• Turn off and on the power again after changing [RS connection].
• When the [RS connection] is set to Thermometer, the communications speed is fixed at
2400 bps.
• When there is no communication with the thermometer, or when no temperature data can be
acquired, measurement data is displayed as “------”.
Acquiring Temperature Data
Saving Temperature Data
• See the instruction manual supplied with the thermometer for operating details.
• During temperature measurement, the Hold function on the thermometer is disabled.
Use the instrument’s Hold functions instead."5.3.1 Data Hold Function" (p. 94)
