Appendix2 Measurement Data Saving Format
A3
Appendix
About Status Data
The status data indicates the measurement state when the data was saved, and is displayed as a 32-bit
hexadecimal digit, as follows.
HMx : Invalid harmonic parameter (no harmonic sync)
MRx : Motor analysis options A and/or B over range
MPx : Motor analysis options A and/or B peak over
ULM : Motor analysis options A and/or B sync unlocked
UCU : Calculation Impossible (e.g., measurement data is invalid immediately after changing ranges)
HUL : Harmonic sync unlocked
ULx : Channel x sync unlocked
RIx : Channel x current over range
RUx : Channel x voltage over range
PIx : Channel x current peak over
PUx : Channel x voltage peak over
(x is a channel number)
Measurement Value Data Format
Level
0th Order Voltage HU1L000 to HU4L000 HU12L000 HU34L000 HU123L000
0th Order Current HI1L000 to HI4L000 HI12L000 HI34L000 HI123L000
0th Order Power HP1L000 to HP4L000 HP12L000 HP34L000 HP123L000
Content
0th Order Voltage HU1D000 to HU4D000 HU12D000 HU34D000 HU123D000
0th Order Current HI1D000 to HI4D000 HI12D000 HI34D000 HI123D000
0th Order Power HP1D000 to HP4D000 HP12D000 HP34D000 HP123D000
Phase angle
0th Order Voltage HU1P000 to HU4P000 HU12P000 HU34P000 HU123P000
0th Order Current HI1P000 to HI4P000 HI12P000 HI34P000 HI123P000
0th Order Power HP1P000 to HP4P000 HP12P000 HP34P000 HP123P000
• • •
nth Order the last three digits = n
Level
100th Order Voltage HU1L100 to HU4L100 HU12L100 HU34L100 HU123L100
100th Order Current HI1L100 to HI4L100 HI12L100 HI34L100 HI123L100
100th Order Current HP1L100 to HP4L100 HP12L100 HP34L100 HP123L100
Content Percent-
age
100th Order Voltage HU1D100 to HU4D100 HU12D100 HU34D100 HU123D100
100th Order Current HI1D100 to HI4D100 HI12D100 HI34D100 HI123D100
100th Order Current HP1D100 to HP4D100 HP12D100 HP34D100 HP123D100
Phase angle
100th Order Voltage HU1P100 to HU4P100 HU12P100 HU34P100 HU123P100
100th Order Current HI1P100 to HI4P100 HI12P100 HI34P100 HI123P100
100th Order Current HP1P100 to HP4P100 HP12P100 HP34P100 HP123P100
Noise Measurement Items
Noise
Voltage UNf01 UN01 to UNf10 UN10
Current INf01 IN01 to INf10 IN10
bit 31 bit 30 bit 29 bit 28 bit 27 bit 26 bit 25 bit 24
HM4 HM3 HM2 HM1 MRB MRA MPB MPA
bit 23 bit 22 bit 21 bit 20 bit 19 bit 18 bit 17 bit 16
ULM ---- UCU HUL UL4 UL3 UL2 UL1
bit 15 bit 14 bit 13 bit 12 bit 11 bit 10 bit 9 bit 8
RI4 RI3 RI2 RI1 RU4 RU3 RU2 RU1
bit 7 bit 6 bit 5 bit 4 bit 3 bit 2 bit 1 bit 0
PI4 PI3 PI2 PI1 PU4 PU3 PU2 PU1
General Measurement
Values
±E±
6-digit decimal mantissa and 2-digit exponent ("+" sign and leading zero are omitted for mantissa.)
Integration Value
±E±
7-digit decimal mantissa and 2-digit exponent ("+" sign and leading zero are omitted for mantissa.)
Time
YYYY/MM/DD
//
HH:MM:SS ::
Elapsed Time
::
Elapsed Time (ms) 
Error state
Input out of range +9999.9E+99
