Hioki 3390 - Page 39

3.9 Selecting the Wiring Mode
31
3
Chapter 3 Measurement Preparations
Wiring configuration diagram
Wiring Mode 1. Single-phase, 2-wire (1P2W) × 4
Wiring configuration diagram
See
Pages 172 and 173 for addi-
tional wiring diagrams.
Wiring Mode 2. Single-phase, 3-wire (1P3W) + single-phase, 2-wire (1P2W) × 2
Wiring Mode 3. 3-phase, 3-wire (3P3W2M) + single-phase, 2-wire (1P2W) × 2
