Louver Open/Close
This function is used to fully open louver for adjusting the vertical deector for air ow direction (manually).
This function cannot be set when the unit is operating.
1 Select “Louver Open/Close” from the menu and press “OK”.
Menu
Motion Sensor Setting
Total Heat Exchanger SET
VENTI
Louver Open/Close
02
/
03
Louver Setting
15:10(Fri)
ENT
TN.SEL.
OK
OK
OK
2 Select “Yes” by pressing “ ” or “ ” and press “OK”. The lou-
ver will be open (closed) and the screen will return to the nor-
mal mode.
NOTE
Refer to Installation & Operation Manual for Indoor Units regarding the
adjustment of air ow direction.
OK
Open louver?
Louver Open/Close
Yes No
SEL. ENT
TN.
OK
OK
Ventilation
Function
• A/C (Air Conditioning): To operate the air conditioner individually.
• VENTI (Ventilation): To operate the total heat exchanger individually.
• A/C+VENTI: To operate the air conditioner and the total heat exchanger together.
NOTE
This function is available only when the total heat exchanger is connected.
1 Select “VENTI” from the menu and press “OK”.
Menu
Motion Sensor Setting
Total Heat Exchanger SET
VENTI
Louver Open/Close
02
/
03
Louver Setting
15:10(Fri)
ENT
TN.SEL.
OK
OK
OK
By repeatedly pressing “ ” or “ ”, the indication is changed in
order of “A/C”, “VENTI” and “A/C + VENTI”. Select the operation
target and press “OK”, then the conrmation screen is displayed
OK
VENTI
SEL'D UNIT
A/C + VENTI
ENT
TN.ADJ
OK
OK
4 Individual remote controls
PC-ARF
TCGB0106 rev.0 - 12/2014
100
