4 Individual remote controls
PC-ART
TCGB0106 rev.0 - 12/2014
133
4
Items
Optional Func-
tion
Indi-
vidual
Setting
Setting
Condi-
tion
Contents
F5
Automatic
Cooling Tem-
perature Re-
lease
×
19 19 ºC
20 20 ºC
21-24 (21-24) ºC
25
25 ºC (Factory
setting)
26-28 (26-28) ºC
29 29 ºC
30 30 ºC
F6
Automatic
Heating Tem-
perature Re-
lease
×
19 19 ºC
20 20 ºC
21-24 (21-24) ºC
25
25 ºC (Factory
setting)
26-28 (26-28) ºC
29 29 ºC
30 30 ºC
F7
Prevention
of Operation
Stoppage due
to Remote
Control Oper-
ating Error
× 00 Not Available
01 Available
F8
Lock Function
for Operation
Mode Selec-
tion
×
00 Not Available
01
Available (Facto-
ry-Setting)
F9
Lock Function
for Tempera-
ture Setting
×
00 Not Available
01
Available (Facto-
ry-Setting)
FA
Lock Function
for Fan Speed
Selection
×
00 Not Available
01
Available (Facto-
ry-Setting)
Fb
Lock Function
for Swing Lou-
ver Operation
×
00 Not Available
01
Available (Facto-
ry-Setting)
FC
Cooling Lower
Limit for Set-
ting Tempera-
ture (*3)
×
00 Standard
01
Lower Limit +1
ºC
02
Lower Limit +2
ºC
... ...
09
Lower Limit +9
ºC
10
Lower Limit +10
ºC
Fd
Heating Upper
Limit for Set-
ting Tempera-
ture (*4)
×
00 Standard
01 Upper Limit –1 ºC
02 Upper Limit –2 ºC
...
09 Upper Limit –9 ºC
10
Upper Limit –10
ºC
Items
Optional Func-
tion
Indi-
vidual
Setting
Setting
Condi-
tion
Contents
FE
Not Prepared -
00 Not Used
01
(Use as 00 condi-
tion)
02
FF
Lock Function
for Timer
×
00 Not Available
01
Available (Facto-
ry-setting)
H1
Maintenance
alarm
○
00 Show
01 Hide
H2
No automatic
control indica-
tion
○
00 Show
01 Hide
H3
Operation
mode change
restriction (*4)
○
00
Operation mode
change off (hide
operation mode)
(factory setting)
01
Operation mode
set by the central
control unit +
“FAN” mode
02
Unlimited opera-
tion
H4
Ventilation
changeover
(total heat ex-
changer only)
○
00
Air conditioning
only
01 Ventilation only
02
Air conditioning +
Ventilation
H5
Central control
available after
forced stop-
page.
○
00 Off
01 On
○: Allow individual setting.
×: Setting is used for all the outdoor units
-: Not used
NOTE
*1: The “02” setting may not be available according to the type of indoor unit.
*2: 00: Standard (7-step operation), 01: Draft Prevention (lower 2 steps cut-
off), 02: High ceiling (upper 2 steps cut off)
*3: Applicable to fan, cooling and dry operation modes.
*4: Applicable to heating operation mode.
After at least 3 minutes from the power ON, change the optional setting.
When changing “CF” setting (change of louver swing range), restore the
power supply or allow the louver to make one complete swing fully in the auto
swing mode to apply the optional setting.
The optional settings are different according to the indoor and outdoor unit
models. Check to ensure that the unit has the optional setting or not.
Record the setting conditions for each optional setting in the “Setting” column
of the table.
To Next Page
