6 Building air conditioning controls
CSNET WEB (PSC-A160WEB1)
TCGB0106 rev.0 - 12/2014
444444
Address
(Note 1)
Name Description Read/Write
18 TLIQUID Liquid pipe temperature (Note 2) Read
19 ERROR_CODE Alarm code Read
20 STOP_CAUSE Compressor stop cause Read
21 VALVE_OPEN Indoor unit expansion valve opening Read
22 OPER_CONDITION
Unit operation condition
0: OFF
1: Thermo OFF
2: Thermo ON
3: Alarm
Read
23 DEFROST Defrost Read
24 AMBIENT_TEMP Ambient temperature (Note 2) Read
25 POWER_GROUP Power meter group Read
26 TIMER_DISABLED
Timer disabled
0: Disabled
1: Enabled
Read/Write
27 OPTIONS Options setting Read
28 POWER Calculated power consumption Read
29
~
31
RESERVED Reserved for future use Not used
NOTE
1. Offset position is: 20000 + N*32 + Address as shown in table, where N is unit address. Unit address as set in CSNET WEB BMS con-
îš¿guration dialog. Be careful because we are using address 0 as îš¿rst register and in Mobdus could be used number 1 as îš¿rst value. In
that case, it will be necessary to add 1 to the address calculation.
2. These numbers refer to signed 16-bit value using 2-complement format for negative values.
3. In case that the installation will use more than one CSNET WEB, it will use different device Ids, using Virtual Ids. Refer to the conîš¿gura-
tion of your BMS to Ethernet adapter to know how it works.
4. Register number 10 is used for general alarm status.
