6 Building air conditioning controls
CSNET Manager LT/XT
TCGB0106 rev.0 - 12/2014
577577
6
Power consumption
CSNET Manager saves and calculates the percentage of energy consumption of each indoor unit compared to the outdoor
units, so that the user can consult the level of consumption at any time.
The window is divided into three parts:
1 The upper part allows you to choose the options you want to consult.
2 The central part shows the results of the consultation.
3 The bottom part offers options of saving the results and exiting.
To carry out a consultation:
1 Indicate the starting and nishing dates for which CSNET Manager will carry out the calculations. These dates can be
chosen in the timer which appears by clicking on the arrow to the right of the date.
2 Click on the Get data button.
3 The results of the consultation will appear in the central part as a table.
4 To save the results of the consultation click on the Save to File button.
