NORMAL OPERATION
Part. No. 2400M2501_6 Touchpoint Pro
117 Technical Handbook
13.15 Accessing Help
From the System Status screen navigation bar, select Tool Box, then Help. This help screen will show the date of the last
configuration change, configuration version, previous user, about TPPR and the service contact options.
The configuration version increments every time that parameters are written to the TPPR, including during calibration. The
configuration version can also be used as a check against unauthorised modification of the system.
Select About to view software and firmware versions.
Select Service Contact for details of how to access technical support.
13.16 System State Relays
The Control Module has two System State relays, rated at 30 VDC, 3 A or 250 VAC, 3 A. The contacts are closed in normal
operation and open under the following conditions:
The System Fault relay is open if one or more of the conditions listed in Table 40. are present.
The System Failure relay is open if one or more of the conditions listed in Table 40. are present.
The System State relays and any other relays configured for safety purposes should be wired to a continuously monitored
system for safe operation. This is to ensure that all system faults are detected promptly and appropriate action taken.
Note: During start-up, the System Failure relay is open until the CCB is available.
Note: The Redundant CCB taking over from a failed Master CCB is not considered to be a system failure, and the System
Failure relay will remain in normal state.
System Failure Relay TB4
System Fault Relay TB5
Major power loss
Display unit internal fault
Fuse blown
Module diagnostics checks reported a fault
Controller software diagnostics failure detected
A channel is in inhibit, Fault or Warning state
Relay Test is being conducted in Test Mode
Redundant CCB takes over after Master CCB failed
System is in Test Mode, other than LED and LCD Tests
An output is an a Force or Force Deactivate state
Table 40. System State Relay Operation
13.16.1 ROM Output Relays on System Fail
Note: if there is a system failure all ROM output relays will de-energise, regardless of their configured states.
