TECHNICAL SPECIFICATIONS
Part. No. 2400M2501_6 Touchpoint Pro
169 Technical Handbook
21.4 Power Supplies and Fuses
21.4.1 Power Supply Units
Power Supply
120 W (5 A)
240 W (10 A)
480 W (20 A)
Input Voltage Range
85 – 276 VAC; 88 – 187 VDC
Input Frequency Range
50 – 60 Hz ± 6%
Input AC current
1.10 A at 120 VAC
0.62 A at 230 VAC
2.22 A at 120 VAC
1.22 A at 230 VAC
4.56 A at 120 VAC
2.48 A at 230 VAC
Output Voltage
DC 24 V (Adjustable 24 – 28 VDC)
DC OK Relay contact ratings
(max.)
60 VDC
@
0.3 A / 30 VDC
@
1 A / 30 VAC
@
0.5 A resistive load
Protection
Short Circuit, Overload protected. Over-Volt, Over-Temp
Dimension
40 x 124 x 117 mm
(W x H x D)
60 x 124 x 117 mm
(W x H x D)
82 x 124 x 117 mm
(W x H x D)
Operating Temperature
–25 °C to +60 °C (–13 °F to +140 °F)
De–rating (60°C to 70°C)
3 W / °C
6 W / °C
12 W / °C
Storage Conditions
–40° to +85° C (–40° F to +185° F), 5 to 95 %RH (non–condensing)
Operating Humidity
5 to 95 %RH (non–condensing)
21.4.2 DIN Rail (Module Supply and Communication)
Description
Standard DIN Rail – used for mounting Power Supplies, Backplanes and Modules
Total Width
430 mm / 487 mm (Options)
Type
TS–35/15
21.4.3 Ring Coupling Module (RCM)
Description
Module for signal connection of DIN Rail mounted I/O modules to Ring Network
Electrical Connection
2 x Ring Network TX / RX Driver Pairs (Each two-wire plus Drain)
Supply Voltage
18 – 32 VDC
Power Consumption
Maximum 1 W
Power Dissipation
Maximum 1 W
Ring Network Cable
Good quality RS485, shielded twisted pair plus Drain and Overall Screen
Operating Temperature
–40°C to +70°C
Storage Temperature
–40°C to +70°C
Environmental Protection Class
Equipment Class III, Installation Cat 2, Pollution Degree 2
