TECHNICAL SPECIFICATIONS
Part. No. 2400M2501_6 Touchpoint Pro
166 Technical Handbook
21.2 Wall Mounted Enclosures
21.2.1 Wall Mount Controller Enclosures with User Interface
These units can be installed indoors or outdoors in a Pollution Degree 3 environment, but one which affords total protection
from rain, snow and direct UV rays (sunlight).
100 – 240 VAC; 50/60 Hz; 1250 W max or 24 VDC nominal (18 – 32 VDC); 1500 W
max. W max is dependent on module and PSU configuration.
Equipment Class 1 (grounded)
2000 m ASL max. in permanently-connected continuous operation.
21.2.2 Wall Mount Remote Unit Enclosures without User Interface
These units can be installed indoors or outdoors in a Pollution Degree 4 environment, and can be exposed to rain, snow and
direct sunlight.
100 – 240 VAC; 50/60 Hz; 1250 W max or 24 VDC nominal (18 – 32 VDC); 1500 W
max. W max is dependent on module and PSU configuration.
Equipment Class 1 (grounded)
2000 m ASL max. in permanently-connected continuous operation.
-25 °C to +55 °C (Remote version with PSU’s) or
Protect the User Interface from direct exposure to precipitation and sunlight.
AVERTISSEMENT
Protéger l’interface utilisateur des expositions directes au soleil et de la pluie.
