Honeywell touchpoint Pro Technical Handbook

TECHNICAL SPECIFICATIONS
Part. No. 2400M2501_6 Touchpoint Pro
173 Technical Handbook
21.5 Control Module and User Interface
21.5.1 Controller & Remote Unit DC Input Supply
Input Voltage
DC 24 V (nominal)
DC Input Voltage Range
18 – 32 VDC (Supplied from Self Enclosed Low Voltage source only)
21.5.2 Control Module and User Interface
Description
Front panel User Interface Assembly
Supply Voltage
18 – 32 VDC (Supplied from Self Enclosed Low Voltage source only)
Power Consumption
Maximum 13 W
Ring Communication Physical
layer
Isolated RS485
Ring Network Cable
Two x 1 mm
2
twisted pair cable
Relay Outputs
Two x System State Relays
Relay Contacts
Min. 12 VDC, 10 mA
Max. 5 A at 250 VAC / 30 VDC (non–inductive)
Interfaces
5.7 inch, 320 x 240 pixels (QVGA), Touch Screen LCD
LED and Button Panel with LEDs for Power, Alarm and Fault indication.
Buttons for Accept and Reset functions
Buzzer for audio indication of Alarm/Faults (Sound Level: 85 dB at 100 mm)
USB 2.0 Device Interface with standard Type B USB connector to interface with
PC/Laptop for configuration. Supports FAT32 USB memory device up to 32 Gb.
Industrial grade devices recommended.
Standard FAT32 SD Card Interface 4 Gb to 32 Gb
Supports 24 mm x 32 mm x 2.1 mm cards. Industrial grade cards recommended.
10/100 Mbps Ethernet Interface with standard RJ–45 connector
Two x RS–485 Modbus connections supporting maximum 115.2 kbps
Panel Dimension
483 mm x 222 mm
Retention of Real Time Clock
72 hours unpowered

Honeywell touchpoint Pro Specifications

General

Brand	Honeywell
Model	touchpoint Pro
Category	Control Systems
Language	English
