CONFIGURATION
Part. No. 2400M2501_6 Touchpoint Pro
75 Technical Handbook
9.2.25 Custom Fault ‘X’ Detail Settings
The Fault details can be set for each of the enabled custom faults.
Access Level: Engineer
Parameter Name
Default Setting
Value Range
Comment
Custom Event (1-5)
Name
‘Custom Fault 1’
Maximum 20
Alphanumeric
Characters
This is the fault description, which will be
displayed on the ‘Input Details’ screen
Custom Event (1-5)
Level Max
3.0 mA
1.0 to 3.9 mA
The recommended minimum difference
between Fault Level Max and Fault Level Min
is 0.2 mA
Custom Event (1-5)
Level Min
2.0 mA
0.8 to 3.8 mA
Custom Event (1-5)
Latch
Latching
Non-Latching /
Latching
Custom Event (1-5)
Type
Fault
Fault / Warning
Select whether the ‘custom fault’ should be
treated as a fault condition or as a warning
condition.
9.3 Analogue Input Module mV Bridge Parameters
The Analogue Input Module mV Bridge has the option to use the sensor catalogue (basic / extended), configure a custom
channel, or copy from a configured channel (basic / extended).
Note: When making changes using extended options, it is the user’s responsibility to determine whether other settings have
been affected and to make any corresponding changes.
If a basic configuration is selected, only the first two screens detailed below will be used (Commission Channel and Field
Device Selection). The rest of the configuration will be programmed automatically, either from the sensor catalogue or from
the channel that is being copied.
Note: If a channel is configured from the sensor catalogue, it is possible to edit individual settings afterwards.
Note: For catalytic bead type detectors, the Touchpoint Pro controller is necessary to complete the measuring circuit.
Therefore all commissioned mV channels remain in Inhibit state until they are calibrated.
9.3.1.1 Configuring Custom Sensors
When configuring a custom sensor, it is the user’s responsibility to select suitable units and ranges. TPPR does not check or
validate all possible combinations.
9.3.2 Commission Channel
Access Level: Administrator
Parameter Name
Default Setting
Value Range
Comment
Channel ID
Next available
1 to 64
Can only be assigned during first time
configuration. Otherwise de-commission the
channel and re-assign another channel number
Channel Tag
‘Channel <Channel
ID>‘
Maximum 30
Alphanumeric
Characters
30 character location tag name. This is the main
channel description used throughout the
interface
Custom Channel
ID
‘Channel <Channel
ID>‘
Maximum 20
Alphanumeric
Characters
20 character custom ID. This is displayed on the
‘Channel Details’ screen and in the
Configuration Report
Note: Channel Tag and Channel Custom ID only require Engineer level access for editing.
