Honeywell touchpoint Pro - Table 27. Query Poll Register; Table 28. Query Poll Register Values; Table 29. Query Poll Descriptions; Table 30. Query Poll Types

CONFIGURATION
Part. No. 2400M2501_6 Touchpoint Pro
99 Technical Handbook
6
40501
40502
40503
40504
40505
40506 to 40536
7
40601
40602
40603
40604
40605
40606 to 40636
8
40701
40702
40703
40704
40705
40706 to 40736
9
40801
40802
40803
40804
40805
40806 to 40836
10
40901
40902
40903
40904
40905
40906 to 40936
Table 27. Query Poll Register
Allowed values for the Result register 40n05 (n = 0 to 9):
Value
Meaning
0
Success
1
Command not permitted
2
Inter process communication failure
67
Failure
Table 28. Query Poll Register Values
11.3.2 Query Poll Descriptions
Poll No
Description
Response
Format
02
Read System Label
B
39
Read Alarm 1 level
A
40
Read Alarm 2 level
A
41
Read Alarm 3 level
A
42
Read STEL level
A
43
Read LTEL level
A
44
Read Rate level
A
102
Read Gas Name
B
103
Read Channel Tag Name
B
104
Read Gas Unit
B
Table 29. Query Poll Descriptions
Response formats for the Result String registers 40n06 - 40n36 (n = 0 to 9):
Type
Format
A
Float (4 Bytes – 32 bit floating point)
B
Unicode String – 35 (Unicode chars) + 1(null)
Table 30. Query Poll Types
Example: Read Alarm 1 level (Query Type):
Register
Block
Active
(40n01)
Channel Type
(40n02)
Channel ID
(40n03)
Query Type
(40n04)
Result (40n05)
Result String (40n06 to
40n36)
