9.5 Relay Output Module Parameters
Relay Output Module (ROM) channels may be configured as blank channels, or by copying an existing configured channel.
If configured by copying another channel, it is possible to edit individual settings.
Note that if there is a system failure all ROM module relays will de-energise, regardless of their configured states.
9.5.1 Commission Channel
Access Level: Administrator
Parameter Name
Default Setting
Value Range
Comment
Channel ID
Next available
1 to 128
Can only be assigned during first time
configuration. Otherwise de-commission the
channel and re-assign another channel number
Channel Tag
‘Channel <Channel ID>‘
Maximum 30
Alphanumeric
Characters
30 character location tag name. This is the main
channel description used throughout the interface
Channel Custom ID
‘Channel <Channel ID>‘
Maximum 20
Alphanumeric
Characters
20 character custom ID. This is displayed on the
‘Channel Details’ screen and in the Configuration
Report
Note: Channel Tag and Channel Custom ID only require Engineer level access for editing
9.5.2 Relay Output Settings
Access Level: Engineer
Parameter
Name
Default Setting
Value Range
Comment
Normal State
De-energised
De-energised /
Energised
The NC contact is closed
Latch Function
Non-Latching
Non-Latching /
Latching
The alarm conditions are usually already configured
as latching; therefore the output channel is
configured non-latching as the default setting.
Delay Time
00m:00s
00m:00s to 05m:00s
The output module will activate the output channel
after the ‘Delay Time’ interval has expired. This
only applies for the transition ‘normal to active’.
Hold Time
00m:00s
00m:00s to 60m:00s
The output module will set the output channel into
normal condition after the ‘Hold Time’ interval has
expired. This only applies for the transition ‘active
to normal’ and only if the output is configured as
non-latching.
Auxiliary Output
Enable
Disabled
Enabled / Disabled
If enabled the system will report any auxiliary
output overload as a fault. The overload condition
applies to the module, so it will be reported on all
enabled channels.
Alarm Update
Enable
Enabled
Enabled / Disabled
If enabled, only unacknowledged alarm conditions
will be considered during C&E evaluation for this
output channel.
An alarm acknowledgement will reset a relay output
that is configured for alarm update function.
However if the alarm update is NOT enabled the
relay contact will only be reset if the alarm is reset.
Action on New
Event
Steady
Steady / Pulsed
Default is set to hold the relay on, but could be set
to pulse the output, e.g. for a beacon or sounder.
Note: Action on New Event only applies if Alarm Update function is enabled.
