16.4 Configuration Settings Test
Engineer access level is required.
During this test, all field device inputs will be ignored by the TPPR. The Cause and Effect matrix will not be evaluated. No
outputs will be generated.
The purpose of this test is to check that input channels are configured correctly, including alarm, warning, fault thresholds
etc. The gas concentration and alarm states raised by forcing the input value can be viewed on the TPPR UI or the PC GUI.
The system fault relay will be open.
16.4.1 How to use the Configuration Settings Test Mode
1. Login as an Engineer.
2. From the System Status screen select the Tool Box icon:
3. Select Diagnostics.
4. Select the Menu icon:
5. Select Configuration Settings Test.
6. The system will ask you to confirm; select Yes to proceed.
7. The system will display a confirmation message, click on OK and you will be automatically navigated to the Inputs
screen.
8. Select the channel to be tested and select Input Details from the popup menu.
9. From the Input Details screen, select the Menu icon:
10. Select Force Value.
11. Enter the gas concentration that you want to simulate. This can include over and under range values.
12. The system will return to the Input Details screen, where it will show the simulated gas value as well as
any corresponding active events (e.g. Alarm 1).
13. When ready, select the Menu icon:
14. Select Clear Force.
15. Repeat steps 9 – 14 as required, completing the channel tests.
16. Return to the Inputs screen and repeat steps 8 – 14 for the next channel.
17. When the test is complete, go to the System Status screen and select the Tool Box icon:
18. Select Diagnostics.
19. Select the Menu icon:
20. Select Stop Configuration Settings Test.
21. The system will show a confirmation message that it has returned to normal operation.
Check and ensure that the system is restored to normal operation once all testing is finished.
