CONFIGURATION
Part. No. 2400M2501_6 Touchpoint Pro
66 Technical Handbook
9.1.1 Displayed Numeric Resolution
Touchpoint Pro displays numeric values to the following resolutions:
9.2 Analogue Input Module 4-20 mA Parameters
The Analogue Input Module 4-20 mA has the option to use the sensor catalogue (basic / extended), configure a custom
channel, or copy from a configured channel (basic / extended).
Note: When making changes using extended options, it is the user’s responsibility to determine whether other settings have
been affected and to make any corresponding changes.
If a basic configuration is selected, only the first two screens detailed below will be used (Commission Channel and Field
Device Selection). The rest of the configuration will be programmed automatically, either from the sensor catalogue or from
the channel that is being copied.
Note: If a channel is configured from the sensor catalogue, it is possible to edit individual settings afterwards.
9.2.1.1 Configuring Custom Sensors
When configuring a custom sensor, it is the user’s responsibility to select suitable units and ranges. TPPR does not check or
validate all possible combinations.
9.2.2 Commission Channel
Access Level: Administrator
Can only be assigned during first time
configuration. Otherwise de-commission the
channel and re-assign another channel number
Maximum 30
Alphanumeric
Characters
30 character location tag name. This is the main
channel description used throughout the
interface
Maximum 20
Alphanumeric
Characters
20 character custom ID. This is displayed on the
‘Channel Details’ screen and in the Configuration
Report
Note: Channel Tag and Channel Custom ID only require Engineer level access for editing.
