11.2.3 Animation Registers
A group of animation values are allocated for registers 30065 to 30128. These are intended to be used by graphics
packages for defining the colours of various screen objects based upon the status of a channel.
A 16 bit unsigned word format is used.
Table 25. Modbus Channel Animation Register
The data value for each register can be one of the following:
Channel operating normally
Table 26. Modbus Channel Animation Register Continued
11.3 Register Allocation for Function 03 / 06 / 16 – Read / Write Holding Registers
All registers use 16 bit data words.
The Channel Type field identifies the channel as Input or Output. The decimal value 105 (= ASCII ‘i’) is used for Inputs, the
decimal value 111 (= ASCII ‘o’) for Outputs. The decimal value 6 together with channel ID 0 is used for master commands.
Function 16 can be used to write to the 40n01 to 40n04 and 41n01 to 41n05 (n = 0 to 9) ranges of registers only.
Caution: When using Function 6 or Function 16, ensure that the registers related to the command are completely filled
before setting the Block Active flag; otherwise an unintended command may be performed.
