TECHNICAL SPECIFICATIONS
Part. No. 2400M2501_6 Touchpoint Pro
174 Technical Handbook
21.6 I/O Modules
21.6.1 Common Specifications
Dimensions
35.0 mm x 99.5 mm x 114.5 mm (W x H x D)
Installation
May be fitted to 5, 7, 9 or 10-way Communication / Power Rail
Maximum wire size
2.5 mm
2
IP Rating
IP20
EMC
EN 50270
Power supply
18 – 32 VDC
Casing material
Polyamide PA 6.6 V0 (UL94)
Operating Temperature Range
–40 °C to +70 °C
Storage Conditions
–40 °C to +70 °C
Operating Humidity Range
10 to 90 %RH (non–condensing)
Weight
210 g
Environmental Protection Class
Equipment Class III, Installation Cat 2, Pollution Degree 2
21.6.2 Analogue Input Module mA
Description
4-channel 4 – 20 mA Analogue Input Module with two or three-wire interface to
detector
Sensor Configuration
4 x two-wire or three-wire sink only (current sourced from detector)
Signal Measurement Range
0 – 25 mA
Supply Voltage
18 – 32 VDC (Supplied from Self Enclosed Low Voltage source only)
Field Device Supply Voltage
Supply Voltage (Vs) – 0.7 V
Single Channel Field Device
Supply current
Maximum 1 A
Total Field Device supply
current
Total Maximum current : 2 A at 70 °C ambient
Total Maximum current : 4 A at 60 °C ambient
Power Consumption
0.8 W (Excluding sensor supply)
Power Dissipation
Maximum 3.7 W, at 4 A total field device load
Maximum 2.1 W, at 2 A total field device load
Sense Resistance
101 Ω
Connector Coding
Analogue Input Module connectors (TB1–TB4) have coding keys to avoid
incorrect wiring
