Honeywell touchpoint Pro Technical Handbook

ORDERING
Part. No. 2400M2501_6 Touchpoint Pro
183 Technical Handbook
23.2 TPPR Components Part Numbers
The following table lists some common TPPR components that are held by your local Honeywell Service Centre.
Item
Description
Part Number
01
SD Card, 4 Gb, FAT32
TPPR-V-0842
02
Analogue Input Module 4-20 mA
TPPR-V-1000
03
Analogue Input Module mV-Bridge
TPPR-V-1010
04
DC-UPS 40 A Module
TPPR-V-0501
05
Digital Input Module
TPPR-V-1030
06
Relay Output Module
TPPR-V-1040
07
Ring Coupling Module
TPPR-V-1050
08
Power Supply Redundancy Module 40 A
TPPR-V-0500
09
PSU 10 A, 240 W, 24 VDC
TPPR-V-0503
10
PSU 20 A, 480 W, 24 VDC
TPPR-V-0504
11
PSU 5 A, 120 W, 24 VDC
TPPR-V-0502
12
Battery Sealed Lead-Acid 12 Ah 12 V (pair)
TPPR-V-0406
13
Battery Sealed Lead-Acid 27 Ah 12 V (pair)
TPPR-V-0405
14
Modbus
®
Interface Board
TPPR-V-2130
15
Redundant Control Centre Board
TPPR-V-2120
16
Battery Fuse 20 A (Cartridge)
Local Purchase
17
Backplanes Fuse 20 A (White Bladed)
Local Purchase
18
CMA, Light & Fan Fuse 5 A (Brown Bladed)
Local Purchase
19
UPS Fuse 25 A (Yellow Bladed)
Local Purchase
Table 50. Spare Parts List
Please contact your local Honeywell Service Centre (see back page) if you want to order these parts as spares.
Some items are not listed as they are only available to Honeywell Service Centres, OEMs and Partners.
Unlisted expendable items (i.e. air filters) will be replaced as part of routine Field Service if required.
WARNING
The equipment specified in this manual is only to be installed by the Manufacturer’s trained personnel, or by
competent persons trained in accordance with the Manufacturer’s installation instructions.
.
