Honeywell touchpoint Pro Technical Handbook

CONFIGURATION
Part. No. 2400M2501_6 Touchpoint Pro
67 Technical Handbook
9.2.3 Field Device Selection
Access Level: Administrator
Parameter
Name
Value Range
Comment
Field Device
Type
Maximum 30
Alphanumeric Characters
If the sensor catalogue is used, a list of available field devices will be
displayed for selection.
If copy channel is being used, this value cannot be changed
Sensor Variant
Maximum 30
Alphanumeric Characters
If the sensor catalogue is used, a list of available gases and ranges
will be displayed for selection.
If copy channel is being used, this value cannot be changed
9.2.4 Sensor Settings
Access Level: Administrator
Parameter
Name
Value Range
Comment
Gas Name
Maximum 10 Alphanumeric Characters
Gas Unit
%FSD, %LEL, % Vol., ppm, ppb, mA, mV, mg/m3, LEL.m
or maximum 5 Alphanumeric Characters
FSD – Full Scale Deflection
LEL – Lower Explosive Limit
LEL.m – LEL metres
9.2.5 Range Settings
Access Level: Administrator
Parameter Name
Default Setting
Value Range
Comment
Signal Range Min
4 mA
0.5 mA to 4 mA
x = Measured signal value
X1 = Signal Range Min (Electrical input from Sensor)
X2 = Signal Range Max (Electrical input from Sensor)
Y1 = Gas Range Min
Y2 = Gas Range Max
Gas concentration (y) is calculated as follows:
y = (((Y2-Y1)/(X2-X1))*(x-X1))+Y1
Signal Range Max
20 mA
12 mA to 24 mA
Gas Range Min
0
0 to 99999
depending on
selected sensor
type.
Gas Range Max
Depends on
sensor type
selected
0.01 to 99999
depending on
selected sensor
type.
9.2.6 Display Settings
Access Level: Administrator
Parameter Name
Default Setting
Value Range
Comment
Full Scale Exceeded
Enable
Enabled for mV
channels
Disabled for mA
channels
Enabled /
Disabled
The Full Scale Exceeded warning is set if the gas
reading rises above the configured full scale value and
it clears when the value falls below the full scale value.
The peak value may be seen in the Trend graph.
