Honeywell touchpoint Pro Technical Handbook

TECHNICAL SPECIFICATIONS
Part. No. 2400M2501_6 Touchpoint Pro
165 Technical Handbook
21.1.2 Rack Unit Model 19 inch 5U Assembly (Local or Remote)
Supplied with a PSU and Modules; Local with a Controller, PCBs and SD Card.
Part Number
TPPR-S-XXXX
Material
Mild Steel
Earth (Ground) Points
M8 (main grounding) other M6
Dimensions (H x W x D)
483 x 222 x 110 mm
Weight
12 Kg with interface, 6 Kg without
Electrical Rating
100 – 240 VAC (±10 % of nominal supplied voltage), 50/60 Hz, 5 A max, Power Factor > 0.9
or 24 VDC nominal (18 – 32 VDC) 20 A max.
(W max is dependent on subsequent module and PSU configuration.)
Class
Equipment Class 1 (grounded)
Altitude
2000 m ASL max. in permanently-connected continuous operation.
Pollution Degree
2
Ambient Temperature
–40 °C to +70 °C max.
–20 °C to +65 °C (Local with Controller)
–25 °C to +65°C (70 °C de-rated) (Remote with PSU but no Controller)
Humidity
10 to 90 %RH non-condensing
Ingress Protection
Type1 / IP2X*
*Note: to maintain the Type 1 and IP 2X ratings this panel must be fitted to an equivalent certified rack enclosure designed for
use with this front panel with no more than a 6 mm gap that provides a Pollution Degree 2 environment when fitted together in
accordance with the manufacturer’s instructions. It is the end user’s responsibility to ensure that the rack system meets all relevant
approvals, including ensuring adherence to temperature ratings when installed in the end unit/system.
21.1.3 OEM Unit 5U Assembly Only
Front Panel Controller, which includes UI, PCBs and SD Card but no mounting brackets.
Part Number
TPPR-V-0852
Material
Mild Steel w. Membrane panel
Earth (Ground) Points
M8 (main grounding) other M6
Dimensions (H x W x D)
225 x 360 x 70 mm
Weight
4 Kg
Electrical Rating
24 VDC nominal (18 – 32 VDC); 13 W max.
(W max is dependent on subsequent module and PSU configuration.)
Relay Contacts
250 VAC; 50/60Hz; 30 VDC; 5 A max.
Class
Equipment Class 1 (grounded)
Altitude
2000 m ASL max. in permanently-connected continuous operation.
Pollution Degree
2
Ambient Temperature
–20 °C to +65 °C
Humidity
10 to 90 %RH non-condensing
Ingress Protection
N/A (See below for special considerations*)
*Note: to maintain the Type 1 and IP 2X ratings this panel must be fitted to an equivalent certified rack enclosure designed for
use with this front panel with no more than a 6 mm gap that provides a Pollution Degree 2 environment when fitted together in
accordance with the manufacturer’s instructions. It is the end user’s responsibility to ensure that the rack system meets all relevant
approvals, including ensuring adherence to temperature ratings when installed in the end unit/system.
