152
Figure 139 Creating VLANs
Table 40 Configuration items
Item Descri
p
tion
VLAN IDs IDs of the VLANs to be created
Modify the description of the
selected VLAN
• ID—Select the ID of the VLAN whose description string is to be modified.
Click the ID of the VLAN to be modified in the list in the middle of the page.
• Description—Set the description string of the selected VLAN.
By default, the description string of a VLAN is its VLAN ID, such as VLAN
0001.
Configuring the link type of a port
1. Select Network > VLAN from the navigation tree.
2. Click the Modify Port tab.
3. Select the port that you want to configure on the chassis front panel.
4. Select the Link Type option.
5. Set the link type, which can be access, hybrid, or trunk.
6. Click Apply.
A progress dialog box appears.
7. Click Close on the progress dialog box when the dialog box prompts that the configuration
succeeds.
