HP 1910 User Manual

235
• The LLDP operating mode of the port changes from Disable/Rx to TxRx or Tx.
This is the fast sending mechanism of LLDP. With this mechanism, a specific number of LLDPDUs are sent
successively at the 1-second interval to help LLDP neighbors discover the local device as soon as possible.
Then, the normal LLDPDU transit interval resumes.
Receiving LLDPDUs
An LLDP-enabled port operating in TxRx mode or Rx mode checks the TLVs carried in every LLDPDU it
receives for validity violation. If valid, the information is saved and an aging timer is set for it based on
the time to live (TTL) TLV carried in the LLDPDU. If the TTL TLV is zero, the information is aged out
immediately.
Compatibility of LLDP with CDP
You need to enable CDP compatibility for your device to work with Cisco IP phones.
As your LLDP-enabled device cannot recognize Cisco Discovery Protocol (CDP) packets, it does not
respond to the requests of Cisco IP phones for the voice VLAN ID configured on the device. This can
cause a requesting Cisco IP phone to send voice traffic untagged to your device, disabling your device
to differentiate voice traffic from other types of traffic.
By configuring CDP compatibility, you can enable LLDP on your device to receive and recognize CDP
packets from Cisco IP phones and respond with CDP packets carrying the voice VLAN configuration TLV
for the IP phones to configure the voice VLAN automatically. The voice traffic is confined in the
configured voice VLAN to be differentiated from other types of traffic.
CDP-compatible LLDP operates in one of the follows two modes:
• TxRx—CDP packets can be transmitted and received.
• Disable—CDP packets can neither be transmitted nor be received.
Protocols and standards
• IEEE 802.1AB-2005, Station and Media Access Control Connectivity Discovery
• ANSI/TIA-1057, Link Layer Discovery Protocol for Media Endpoint Devices
Recommended LLDP configuration procedure
Ste
p
Remarks
1. Enabling LLDP on ports
(Optional.)
By default, LLDP is enabled on ports.
Make sure that LLDP is also enabled globally, because LLDP can work on
a port only when it is enabled both globally and on the port.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
