(Required.)
Configure the voice VLAN assignment mode of a port as automatic
and enable the voice VLAN function on the port.
By default, the voice VLAN assignment mode of a port is automatic,
and the voice VLAN function is disabled on a port.
3. Adding OUI addresses to the
OUI list
(Optional.)
The system supports up to 128 OUI addresses.
By default, the system is configured with seven OUI addresses, as
shown in Table 45.
Recommended configuration procedure for a port in manual voice VLAN assignment mode
Ste
1. Configuring voice VLAN
globally
(Optional.)
Configure the voice VLAN to operate in security mode and configure the aging
timer.
2. Assigning the port to the
voice VLAN
(Required.)
After an access port is assigned to the voice VLAN, the voice VLAN
automatically becomes the PVID of the access port.
For more information, see "Configuring VLANs."
3. Configuring the voice
VLAN as the PVID of a
hybrid or trunk port
(Optional.)
This task is required if the incoming voice traffic is untagged and the link type
of the receiving port is trunk or hybrid. If the incoming voice traffic is tagged,
do not perform this task.
For more information, see "Managing ports."
4. Configuring voice VLAN
on ports
(Required.)
Configure the voice VLAN assignment mode of a port as manual and enable
voice VLAN on the port.
By default, the voice VLAN assignment mode of a port is automatic, and voice
VLAN is disabled on a port.
5. Adding OUI addresses
to the OUI list
(Optional.)
You can configure up to 128 OUI addresses.
By default, the system is configured with the seven OUI addresses shown
in Table 45.
Configuring voice VLAN globally
1. Select Network > Voice VLAN from the navigation tree.
