HP 1910 User Manual

76
Managing ports
You can use the port management feature to set and view the operation parameters of a Layer 2 Ethernet
port and an aggregate interface.
• For a Layer 2 Ethernet port, these operation parameters include its state, rate, duplex mode, link
type, PVID, MDI mode, flow control settings, MAC learning limit, and storm suppression ratios.
• For an aggregate interface, these operation parameters include its state and MAC learning limit.
Setting operation parameters for a port
1. Select Device > Port Management from the navigation tree.
2. Click the Setup tab to enter the page, as shown in Figure 61.
Figure 61 The Setup tab
3. Set the operation parameters for the port as described in Table 13.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
