18
Function menu Descri
p
tion
User level
Setup Apply a QoS policy to a port. Configure
Remove Remove the QoS policy from the port. Configure
Priority
Mapping
Priority
Mapping
Display priority mapping table information. Monitor
Modify the priority mapping entries. Configure
Port Priority
Port Priority
Display port priority and trust mode information. Monitor
Modify port priority and trust mode. Configure
PoE PoE
Summary
Display PSE information and PoE interface
information.
Monitor
PSE Setup Configure a PoE interface. Configure
Port Setup Configure a port. Configure
Common items on the Web pages
Buttons and icons
Table 2 Commonly used buttons and icons
Button and icon Function
Applies the configuration on the current page.
Cancels the configuration on the current page, and returns to the
corresponding list page or the Device Info page.
Refreshes the current page.
Clears all entries in a list or all statistics.
Adds an item.
,
Removes the selected items.
Selects all the entries in a list, or selects all ports on the device panel.
Clears all the entries in a list, or clears all ports on the device panel.
Buffers settings you made and proceeds to the next step without applying
the settings.
This button is typically present on the configuration wizard.
Buffers settings you made and returns to the previous step without applying
the settings.
This button is typically present on the configuration wizard.
Applies all settings you made at each step and finishes the configuration
task.
This button is typically present on the configuration wizard.
