168
Configuring a voice VLAN
Overview
The voice technology is developing quickly, and more and more voice devices are in use. In broadband
communities, data traffic and voice traffic are usually transmitted in the network at the same time. Usually,
voice traffic needs higher priority than data traffic to reduce the transmission delay and packet loss ratio.
A voice VLAN is configured for voice traffic. After assigning the ports that connect to voice devices to a
voice VLAN, the system automatically modifies quality of service (QoS) parameters for voice traffic, to
improve the transmission priority of voice traffic and ensure voice quality.
Common voice devices include IP phones and integrated access devices (IADs). Only IP phones are used
in the voice VLAN configuration examples in this document.
OUI addresses
A device determines whether an incoming packet is a voice packet by checking its source MAC address.
If the source MAC address of a received packet matches an organizationally unique identifier (OUI) in
the voice device OUI list (referred to as the OUI list in this document) maintained by the switch, the packet
is regarded as a voice packet.
You can add OUI addresses to the OUI list maintained by the device or use the default OUI list shown
in Table 45 f
or voice traffic identification.
Table 45 The default OUI list
Number OUI Address
Vendor
1 0001-e300-0000 Siemens phone
2 0003-6b00-0000 Cisco phone
3 0004-0d00-0000 Avaya phone
4 00d0-1e00-0000 Pingtel phone
5 0060-b900-0000 Philips/NEC phone
6 00e0-7500-0000 Polycom phone
7 00e0-bb00-0000 3Com phone
An OUI address is usually the first 24 bits of a MAC address (in binary format). It is a globally unique
identifier assigned to a vendor by the IEEE. In this document, however, OUI addresses are used by the
system to determine whether received packets are voice packets and they are the results of the AND
operation of a MAC address and a mask. For more information, see "Adding OUI addresses to the OUI
list."
You can remove default OUI addresses and if needed, add them to the OUI list after their removal.
