HP 1910 User Manual

133
Table 37 Configuration items
Item Descri
p
tion
User Name Set the SNMP user name.
Security Level
Select the security level for the SNMP group. Available security levels are:
• NoAuth/NoPriv—No authentication no privacy.
• Auth/NoPriv—Authentication without privacy.
• Auth/Priv—Authentication and privacy.
Group Name
Select an SNMP group to which the user belongs:
• When the security level is NoAuth/NoPriv, you can select an SNMP
group with no authentication no privacy.
• When the security level is Auth/NoPriv, you can select an SNMP group
with no authentication no privacy or authentication without privacy.
• When the security level is Auth/Priv, you can select an SNMP group of
any security level.
Authentication Mode
Select an authentication mode (including MD5 and SHA) when the security
level is Auth/NoPriv or Auth/Priv.
Authentication Password
Set the authentication password when the security level is Auth/NoPriv or
Auth/Priv.
Confirm authentication password must be the same with the authentication
password.
Confirm Authentication
Password
Privacy Mode
Select a privacy mode (including DES56, AES128, and 3DES) when the
security level is Auth/Priv.
Privacy Password
Confirm Privacy Password
Set the privacy password when the security level is Auth/Priv.
Confirm privacy password must be the same with the privacy password.
ACL
Associate a basic ACL with the user to restrict the source IP address of
SNMP packets. To allow or prohibit the specified NMS to access the agent
by using this user name, you can allow or prohibit SNMP packets with a
specific source IP address.
Configuring the SNMP trap function
1. Select Device > SNMP from the navigation tree.
2. Click the Trap tab.
The Trap tab appears.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
